How to Choose Flame Retardant Ratings (VW-1 vs IEC 60332): Understanding Different Application Requirements
As photovoltaic, energy storage, EV charging, and industrial power systems continue to expand, cable safety requirements are becoming increasingly important. Among them, flame retardant performance is one of the key factors in cable selection.
When choosing cables, many engineers and project developers encounter standards such as:
· VW-1
· IEC 60332-1
· IEC 60332-3
But what do these flame retardant ratings actually mean? And how should they be selected for different applications?
This article explains the differences between common flame retardant standards and how to choose the right cable for different installation environments.
Why Flame Retardant Performance Matters？
Cables are widely distributed throughout photovoltaic systems, energy storage stations, buildings, and industrial facilities. Once a cable fire occurs, flames may spread rapidly along cable routes, increasing the risk of equipment damage, system shutdown, and safety accidents.
Flame retardant cables are designed to:
· Reduce flame spread
· Improve system safety
· Lower fire risk
· Protect equipment and infrastructure
· Meet building and project compliance requirements
Different application scenarios require different levels of flame retardant performance.
What Is VW-1?
VW-1 is a flame test standard commonly used in North America, especially for UL-certified cables.
The test evaluates whether a cable can self-extinguish after being exposed to a vertical flame source for a specified period.
Cables passing VW-1 testing generally provide:
· Basic flame retardant capability
· Reduced flame propagation
· Compliance with many industrial and commercial applications
VW-1 is widely used in:
· Equipment internal wiring
· Industrial control systems
· EV charging equipment
· Electronic devices
· Some photovoltaic and energy storage components
For applications with relatively limited cable concentration, VW-1 may already provide sufficient fire safety performance.
What Is IEC 60332?
IEC 60332 is an internationally recognized flame retardant standard widely used in Europe and global energy infrastructure projects.
It includes different testing categories depending on application requirements.
IEC 60332-1
IEC 60332-1 evaluates the flame retardant performance of a single cable under vertical flame conditions.
It is commonly used for:
· Solar cables
· Energy storage cables
· Industrial power cables
· General outdoor cable installations
Cables meeting IEC 60332-1 requirements can effectively reduce flame spread on individual cable installations.
IEC 60332-3
IEC 60332-3 is a more demanding flame retardant standard designed for bundled cable installations.
The test simulates scenarios where multiple cables are installed together in trays or conduits.
It is commonly required for:
· Utility-scale photovoltaic plants
· Data centers
· Commercial buildings
· Energy storage stations
· Tunnels and infrastructure projects
Compared with VW-1 and IEC 60332-1, IEC 60332-3 provides stronger flame spread control in dense cable installation environments.
How to Choose the Right Flame Retardant Rating
The correct flame retardant level depends on the installation environment, project requirements, and safety standards.
For Residential and Rooftop PV Systems
IEC 60332-1 or VW-1 is often sufficient for distributed solar applications where cable routing is relatively simple and cable density is lower.
Key priorities include:
· UV resistance
· Weather resistance
· Basic flame retardancy
· Long-term outdoor durability
For Utility-Scale Solar and Energy Storage Projects
Large-scale projects usually involve long cable routes and concentrated cable installations.
In these scenarios, higher flame retardant standards such as IEC 60332-3 are often preferred to improve overall fire safety and reduce flame propagation risk.
This is especially important for:
· Cable trays
· Containerized energy storage systems
· High-power DC systems
· Indoor electrical rooms
For Data Centers and High-Density Infrastructure
AI infrastructure and data centers require extremely high cable safety standards due to dense cable deployment and continuous operation.
Low-smoke, halogen-free cables with advanced flame retardant performance are often required to:
· Reduce smoke generation
· Improve evacuation visibility
· Protect sensitive equipment
· Reduce toxic gas release during fire events
In these environments, flame retardant performance becomes a critical part of overall infrastructure reliability.
Flame Retardancy Is Not the Only Requirement
A high-quality cable should balance multiple performance factors, including:
· Flame retardancy
· Electrical performance
· Mechanical strength
· UV resistance
· Temperature resistance
· Long-term aging stability
Overemphasizing one parameter while ignoring others may reduce overall system reliability.
For photovoltaic and energy storage systems, cable selection should always consider both safety and long-term operational performance.
SUNKEAN Flame Retardant Cable Solutions
SUNKEAN provides photovoltaic cables, energy storage cables, EV charging cables, and high-speed data cables designed to meet international flame retardant and safety standards.
Our cable solutions support:
· VW-1 flame retardant requirements
· IEC 60332 standards
· Low-smoke halogen-free performance
· Long-term outdoor reliability
· Utility-scale energy infrastructure applications
With advanced manufacturing capability, strict quality control, and international certifications, SUNKEAN continues to deliver safer and more reliable cable solutions for global renewable energy and intelligent infrastructure projects.
Conductor: 18AWG~2000kcmil
Color: Black, red, yellow/green or other colors
Conductor: 14AWG~2000kcmil
Color: Black, red, white or other colors
This cable can be used for photovoltaic inverter AC branch lines.
Conductor: 14AWG~10AWG
Insulation Color: Optional color
Jacket Color: Black
Choosing the correct flame retardant rating is essential for cable safety and long-term project reliability.
VW-1, IEC 60332-1, and IEC 60332-3 are designed for different installation environments and fire safety requirements. Understanding these standards helps project developers and engineers select cable solutions that balance compliance, safety, and system performance.
As photovoltaic, energy storage, and AI infrastructure continue to evolve, flame retardant cable technology will remain a critical part of safe and reliable energy systems.
